Lenze 8400 BaseLine C User Manual

11 Function library
11.3 L_PCTRL_1
314
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C231/1 (Pos. Maximum)
C231/2
(Pos. Minimum)
C231/3
(Neg. Minimum)
C231/4
(Neg. Maximum)
0.0 % 199.9 Operating range
• Determination of the operating
range for the PID process control-
ler by limiting the input signal
nSet_a.
• Lenze setting: No limitation (-
199.9 % ... +199.9 %)
C242
Operating mode
0Off
(Lenze setting)
The input setpoint nNSet_a is output
without any changes at the output
nOut_a.
1 Additive + feedforward control nNSet_a and nAct_a are used as PID
input values. The arriving nNSet_a is
additively linked to the value output
by the PID element.
2 PID as setpoint generator. nSet_a and nAct_a are used as PID in-
put values. The input nNSet_a is not
considered.
3 PID setpoint from L_NSet_1
nNSet_a and nAct_a are used as PID
input values. The input nSet_a is not
considered.
C243
0.0 s 999.9 Influence acceleration time
• Acceleration time T
ir
for the influ-
encing factor.
•Lenze setting: 5.0s
C244
0.0 s 999.9 Influence deceleration time
• Deceleration time T
if
for the influ-
encing factor.
•Lenze setting: 5.0s
C245
-199.9 % +199.9 Display of PID output value
nPIDOut_a
Parameter Possible settings Info
