3 Commissioning
3.4 Commissioning with the »Engineer«
34
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2. Adapting the parameters of the motor control:
 Tip!
Also check the other information on the nameplate against the motor data set in the drive
controller. You can find further information in the chapter entitled "Motor selection/Motor
data". ( 65)
Recommendations for the following application cases:
• If the controller and motor differ greatly from each other in terms of performance:Set
the Imax limit (in motor mode) in C022
to double the rated motor current.
• If a higher starting torque is required:
In idle state of the motor, set the Vmin boost in C016
in such a way that the rated motor
current flows at a field frequency of f = 3 Hz (display in C058
).
• If a high torque is to be available at low speed and without a feedback:Select the "sen-
sorless vector control" (SLVC) in C006
as motor control.
Parameter Lenze setting Info
Value Unit
V/f base frequency
(C015
)
50.0 Hz Adapting the V/f base frequency
( 83)
Imax in motor mode
(C022
)
47.00 A Optimising the Imax controller
( 85)
Vmin boost
(C016
)
0.0 % Adapting the Vmin boost
( 84)
