5 Motor control (MCTRL)
5.1 Motor selection/Motor data
72
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
 How to carry out automatic motor parameter identification:
1. Inhibit the controller if it is enabled, e.g. via the C002/16
device command or a LOW signal
at the X4/RFR terminal.
2. Wait until the drive is at standstill.
3. Transfer the nameplate data to the following codes:
• C081
: Rated motor power
• C087
: Rated motor speed
• C088
: Rated motor current (according to the connection method /)
• C089
: Rated motor frequency (according to the connection method /)
• C090
: Rated motor voltage (according to the connection method /)
• C091
: Motor cos ϕ
4. Start motor parameter identification via the C002/23
device command.
5. Enable the controller again.
• Motor parameter identification starts.
• The progress of the identification can be seen in C002/23
.
• The identification is completed if the "0: Off / ready" message is displayed in C002/23
.
6. Inhibit controller again.
