Lenze E82EV751K4C User Manual

Basic units in the power range 15 ... 30 kW
Mounting with fixing brackets and built-on mains filter
5
Basic device installation
5.5
5.5.3
L
5.5-3
EDS82EV903-1.0-11/2002
5.5.3 Mounting with fixing brackets and built-on mains filter
8200vec276
Fig. 5.5-3 Standard mounting with built-on mains filter 15 ... 30 kW
 Loosebothscrewsinordertoremovethehousingcover.Theassemblykitcan
be found under the housing cover.
 Mounting of the fixing brackets
 Dimensions
0
Mount the drive controllers side by side with a certain space to each other in
order to dismount lifting-eye bolts, if necessary.
Mains filter
Dimensions [mm]
8200 vector
M
a
i
n
s
f
i
l
t
e
r
type A or typ e B
a b1 b4 c c1 d d1 d2 e g k m
E82EV153K4B2x1 EZN3x0110H030
2
5
0
6
8
0
3
6
5
2
0
5
2
2
7
4
0
2
4
7
0
5
2
5
0
6
5
2
4
1
1
E82EV223K4B2x1 EZN3x0080H042
250 680 365 205 22 740 24 705 250 6.5 24 11
E82EV303K4B2x1 EZN3x0055H060 250 680 365 205 22 740 24 705 285 6.5 24 11
