Parameter setting with the XT EMZ9371BC keypad
Display elements and function keys
9
Parameter setting
9.4
9.4.3
L
9.4-3
EDS82EV903-1.0-11/2002
0 Status display basic device
Display Meaning Explanation
d
Ready for operation
c
Pulse inhibit active Power outputs inhibited
b
Adjusted current limitation is exceeded in
motor-mode or generator-mode
B
Speed controller 1 in limitation Drive torque-controlled
(active only when operating with the basic
controllers of the 9300 series)
A
Active fault
1 Adoption of p arameters
Display Meaning Explanation
p Parameters are adopted immediately Basic device operates immediately with the
new parameter value
SHPRG p Parameter must be confirmed with TV Basic device operates with the new
parameter value, after it was confirmed
SHPRG In case of controller inhibit the parameter must
be confirmed with
TV
Basic device operates with the new
parameter value, after the controller has
been enabled
none Display parameter Change not possible
2 Active level
Display Meaning Explanation
Menu Menu level active Select main menu and submenus
Code Code level active Select codes and subcodes
Para Parameter level active Change parameters in the codes or
subcodes
none Operation level active Display operating parameters
3 Short text
Display Meaning Explanation
alphanumerical Contents of menus, meaning of codes and
parameters
In operation level display of C0004 in % and
active fault
4 Number
active level Meaning Explanation
Menu level Menu number Display only active when operating with the
basic device series 8200 vector or 8200
motec
Code level four-digit code number
5 Number
active level Meaning Explanation
Menu level Submenu number Display only active when operating with the
basic device series 8200 vector or 8200
motec
Code level two-digit subcode number
6 Parameter value
Parameter value with unit
7 Cursor
In the parameter level the number above the cursor can be directly changed
8 Function keys
For description see the following table
Display elements
