Lenze E82EV751K4C User Manual

Operating mode
Vector control
10
Function library
10.3
10.3.2
L
10.3-8
EDS82EV903-1.0-11/2002
10.3.2 Vector control
Compared with the V/f characteristic control the vector control offers
considerably higher torque and lower current consumption during idle running.
The vector control is an improved motor current control following the Lenze FTC
technology. Select vector control for operation of the following drives:
l Single drives with extremely changing loads
l Single drives with heavy start conditions
l Sensorless speed control of standard three-phase AC motors
)
))
) Note!
l The connected motor should maximally be two power classes
lower than the motor assigned to the controller.
l The operation with vector control is not possible if several
drives are operated on one controller.
l The motor parameter identification is absolutely vital!
Otherwise commissioning is not possible.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0014
v
Operating mode 2
2 V/f charact eristic control V ~ f
(Linear characteristic with constant V
min
boost)
• Commissioning without motor parameter
identification possible
• Benefit of identification with C0148:
I
m
p
r
o
v
e
d
s
m
o
o
t
h
r
u
n
n
i
n
g
a
t
l
o
w
^ 10.3-1
3 V/f charact eristic control V ~ f
2
(Square-law characteristic with constant V
min
boost)
–
Improved smooth running at low
speed
– V/f ra t e d f re quency (C0015) and slip
(C0021) are calculated and stored.
They do not have to be entered
4 Vector control
For initial selection enter the motor data
f
5 Sensorless to rque control with speed limitation
• Torque setpoint via C0412/6
• Speed limit ation via setpoint 1 (NSET1-N1), if
C0412/1 is a ssigned, if not via max. frequency
(C0011)
and identify the motor parameters with
C0148
Otherwise commissioning is not
possible
C0015
uSEr
V/f rated frequency 50.00 7.50 {0.02 Hz} 960.00 • C0015 is calculated a nd stored under
C0148 when the motor parameters are
identified
• Settings applies to all possible mains
voltages
^ 10.3-3
^ 10.3-8
C0021 Slip compensation 0.0 -50.0 {0.1 %} 50.0 C0021 is calculated a nd stored under
C0148 when the motor parameters are
identified
^ 10.4-1
C0054* Apparent motor
current
(MCTRL1-IMOT)
0.0 {A} 2000.0 Only display
C0087 Rated motor speed à 300 {1 rpm} 16000 à Depending on the controller ^ 10.9-1
C0088 Rated motor
current
à 0.0 {0.1 A} 650.0 à Depending on the controller
0.0 ... 2.0 x rated output current of the
controller
^ 10.9-1
C0089 Rated motor
frequency
50 10 {1 Hz} 960 ^ 10.9-1
