Conditions for a trouble-free network of several drives
Fuses and cable cross-sections for a network of several drives
12
Network of several drives
12.4
12.4.4
L
12.4-7
EDS82EV903-1.0-11/2002
Type Fuses F4, F5 Cable cross-section
1)
mm
2
AWG
E82EV551K2B CC6A 1 18
E82EV751K2B CC8A 1 18
E82EV152K2B CC12A 1.5 16
E82EV222K2B CC16A 2.5 14
E82EV551K4B CC6A 1 18
E82EV751K4B CC6A 1 18
E82EV152K4B CC8A 1 18
E82EV222K4B CC10A 1 18
9341 20A 4 12
9342 40A 10 8
9343 80A 25 3
9364
9365
9321, 8241 6A 1 18
E82EV551K4B, E82EV751K4B 6A 1 18
9322, 8242, 8211 6A 1 18
8212 6A 1 18
9323, 8243 12A 1.5 14
E82EV152K4B, E82EV222K4B 10A 1.5 16
8213, 8214 10A 1.5 16
9324, 8244 12A 1.5 14
E82EV302K4B 16A 2.5 12
8215, E82EV402K4B 16A 2.5 12
9325, 8245, 8216 20A 4 12
E82EV552K4B 25A 4 10
E82EV752K4B 40A 10 8
9326, 8246, 8217, 8218, E82EV113K4B 40A 10 8
9327, 8221, E82EV153K4B 80A 25 3
9328, 8222, E82EV223K4B 80A 25 3
9329, 8223, E82EV303K4B 100A 50 1
9330, 8224, E82EV453K4B 2*80A 2*25 2*3
9331, 8225, E82EV553K4B 2*100A 2*50 2*1
9332, 9333, 8226, 8227, E82EV753K4B,
E82EV903K4B
3*80A 3*25 3*3
1)
Observe national and regional regulations (e . g. VDE0113, EN 60204)!
)
))
) Note!
We recommend to use fuse holders with alarm contact when the
network is supplied decentrally. This serves to switch off the
entire network of drives if one fuse blows.
