Basic units in the power range 0.25 ... 2.2 kW
Mounting in ”cold plate” technique
5
Basic device installation
5.3
5.3.3
L
5.3-6
EDS82EV903-1.0-11/2002
5.3.3 Mounting in ”cold plate” technique
When using ”cold plate” technique the controllers can be mounted to sum
coolers. Use controllers of type E82CV... .
The following points are important to ensure a safe operation of the drive
controllers:
l Good thermal contact with the cooler:
– The contact area between the cooler and the drive controller must be at
least as large as the cooling plate of the drive controller.
– Plane contact area, deviation max. to 0.05 mm.
– The cooler and heatsink must be attached using all the screwed joints
that are specified.
l Thermal resistance R
th
according to table. The values are valid for operation
with the drive controllers under rated conditions.
8200 vector Cooling p ath Ground
Power to be dissipated Heatsink - environment
Type P
loss
[W] R
th
[°C/W] [kg]
E82CV251K2C 15 ≤ 1.50 0.6
E82CV371K2C 20 ≤ 1.50 0.6
E82CV551K2C 30 ≤ 1.00 0.9
E82CV751K2C 40 ≤ 1.00 0.9
E82CV152K2C 70 ≤ 0.30 1.1
E82CV222K2C
1)
100 ≤ 0.30 1.1
E82CV551K4C 30 ≤ 1.00 0.9
E82CV751K4C 40 ≤ 1.00 0.9
E82CV152K4C 65 ≤ 0.30 1.1
E82CV222K4C 100 ≤ 0.30 1.1
1)
Max. output current at 8 kHz chopper frequenc y: 8.5 A!
l Ambient temperature - controllers
– The rated data and the derating for higher temperatures still apply for the
ambient temperature of the drive controller.
l Heat distribution between common heatsinks/coolers within the control
cabinet
– If you mount several components (drive controller, brake units etc.) on a
common cooler, then care must be taken that the temperature of the
controller heatsinks does not exceed 75 °C.
Requirements on the cooler
Environmental conditions
