4.2 Rated data
4.2.1 Overview
Input data
Basis of the data
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f[Hz]
3/PE AC 400 320-0%...440+0% 45-0%...65+0%
3/PE AC 480 432-0%...528+0% 45-0%...65+0%
Voltage Frequency Rated current [A]
Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E84DGDVB3714 400/480 50/60 1.3/1.1 1.0/0.8 3
E84DGDVB5514 400/480 50/60 1.8/1.5 1.4/1.1 3
E84DGDVB7514 400/480 50/60 2.4/2.0 1.8/1.5 3
E84DGDVB1124 400/480 50/60 3.2/2.7 2.4/2.0 3
E84DGDVB1524 400/480 50/60 3.8/3.1 2.9/2.3 3
E84DGDVB2224 400/480 50/60 5.6/4.6 4.2/3.5 3
E84DGDVB3024 400/480 50/60 7.2/5.9 5.4/4.4 3
E84DGDVB4024 400/480 50/60 9.3/7.7 7.0/5.8 3
E84DGDVB5524 400/480 50/60 12.8/10.6 9.6/8.0 3
E84DGDVB7524 400/480 50/60 16.3/13.5 12.3/10.1 3
 Ambient temperature, switching frequency 4 kHz
Output data
Voltage Frequency Rated current [A]
Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E84DGDVB3714 0 ... 400/480 0 ... 300 1.3/1.1 1.0/0.8 3
E84DGDVB5514 0 ... 400/480 0 ... 300 1.8/1.5 1.4/1.1 3
E84DGDVB7514 0 ... 400/480 0 ... 300 2.4/2.0 1.8/1.5 3
E84DGDVB1124 0 ... 400/480 0 ... 300 3.2/2.7 2.4/2.0 3
E84DGDVB1524 0 ... 400/480 0 ... 300 3.9/3.2 2.9/2.4 3
E84DGDVB2224 0 ... 400/480 0 ... 300 5.6/4.7 4.2/3.5 3
E84DGDVB3024 0 ... 400/480 0 ... 300 7.3/6.0 5.4/4.5 3
E84DGDVB4024 0 ... 400/480 0 ... 300 9.5/7.9 7.1/5.9 3
E84DGDVB5524 0 ... 400/480 0 ... 300 13.0/10.8 9.8/8.1 3
E84DGDVB7524 0 ... 400/480 0 ... 300 16.5/13.7 12.4/10.3 3
 Ambient temperature, switching frequency 4 kHz
 Note!
The maximally possible output voltage is approx. 94 % of the mains voltage.
