Technical data
Dimensions
Wall mounting
4
53
EDS84DG752 EN 5.0
4.8.2 Wall mounting
E84DGMWE1001
Dimensions - wall mounting [mm]
Type a b e b1 a1 e1 e2 e3 m[kg]
E84DGDVB371T
161
109 241 34 50 50
16
2)
10
3)
2.8
E84DGDVB551T
E84DGDVB751T
75
(20
1)
)
E84DGDVB112T
E84DGDVB152T
E84DGDVB222T
176 135 261 38
75
(20
1)
)
50 50 10
3)
3.7
E84DGDVB302T
1)
Reduction possible if no free space for plugs or cables/c able glands is required.
Arrangement of several devices only to the sides, so that the convection cooling remains ensured.
2)
With E84DGVN1E or E84DVBWxxxxxxxxxx1
3)
With E84DGVN2E or E84DVBWxxxxxxxxxx2
93
34
93
27.5
e
53
Ø 5.5
e3
10
E84DZMAWE1
E84DG...
[mm]
E84DGHB001
