Technical data
Power terminals
Mains connection
4

45
EDS84DG752 EN 5.0
4.6.1 Mains connection
Pin / name Features Rated value
L1, L2, L3 Mains phases according to rated data
assigned X1:
 Earthing, 2 x in the Wu -
4.6.2 Motor connection
Pin / name Features Rated value
U, V, W Motor phases according to rated data
assigned X1:
 Earthing, 2 x in the Wu -
4.6.3 Motor temperature monitoring
Pin / name Features Rated value
T1, T2 Motor temperature monitoring according to rated data
4.6.4 Motor holding brake connection
Pin / name Feature Rated value
BD1 (+)
BD2 (-)
Connection of a motor holding brake
Output voltage
(depending on mains voltage)
AC 400 V DC 180 V
AC 480 V DC 215 V
Max. output current 0.3 A
Max. output power 55 VA
Time-dependent behaviour See software manual, chapter ”Holding brake
control/parameter setting”
Short-circuit strength No
Reset and switch-on behaviour Outputs are switched off
Operating frequency Max. 30/min
4.6.5 Connection of brake resistor
Pin / name Features Rated value
Rb1, Rb2 Brake resistor according to rated data
