4.7.2 Digital output
X4
Pin / name Features Rated value
DO1 Digital output 24 V DC
50 mA
4.7.3 Analog input
The analog input is only available with the modules
ƒ Communication in the ”Advanced” version or
ƒ Standard I/O.
X4
Pin / Name Feature Rated value
AU
GND
Voltage input
0...10V
Input resistance >80k
Sampling frequency 80 Hz (12 ms)
Accuracy  0.1 V
Electric strength of external voltage -7 ... +30 V
A/D converter 10 bit resolution
AI
GND
Current input, parameterisable
0.6 ... +20 mA (I < 0.6mA ≙ ”0”)
4 ... +20 mA, fail -safe
Input resistance 250 
Input current in case of open circuit Display ”0” (I < 0.6 mA)
Sampling frequency 80 Hz (12 ms)
Accuracy  0.2 mA
Electric strength of external voltage -7 ... +7 V
A/D converter 10 bit resolution
4.7.4 Connection of relay output
X4
Pin / name Features Rated value
COM
NO
Switching contact, NO contact,
potential-free
24 V DC, 2 A not inductive
250 V AC, 2 A
