Commissioning
Quick commissioning
6
78
EDS84DG752 EN 5.0
6.2 Quick commissioning
Stop!
Automatic motor start
In ”Local mode” The auto-start option ”Inhibit at power-on” is not set. When
the mains is connected, the motor starts if the controller enable RFR is bridged
or set.
(”Localmode”=>DIP1/1=ONandDIP2/5-7=OFF)
Possible consequences:
ƒ Danger or damages through unexpected motor start.
Protective measures:
ƒ Decouple the motor from the drive train during commissioning phase.
ƒ Replace the factory-set bridge at RFR by an NO contact.
ƒ Do not set controller enable.
