Lenze ECSEE040 User Manual

Configuration
Overview of monitoring functions
8

109
EDBCSXE040 EN 6.0
8.3 Overview of monitoring functions
Responses ( 111) of monitoring functions can be parameterised partly via codes ˘ in the GDC parameter menu under
Monitoring.
Monitoring Possible responses
l Lenze setting
ü Setting possible
Fault message Description
Code TRIP Short−circui
t brake TRIP
Message Warning Off
0011 OC1 Short circuit in the DC bus ü l ˘ ˘ ˘
0012 OC2 Earth fault in the DC bus ü l ˘ ˘ ˘
0013 OC3 Load of the DC bus during load process (from operating system V2.3) ü l ˘ ˘ ˘
0014 OC4 Short circuit/overload of brake resistor or IGBT l ˘ ˘ ˘ ˘
0015 OC5 Device utilisation I x t (fix 100%) ü l ˘ ˘ ˘
0016 OC6 Overload of internal brake resistor C0579 l ˘ ˘ ü
0020 OU Overvoltage in the DC bus (C0173) ü l ˘ ˘ ˘
1031
2031
LP0 Mains voltage outside the operating range ˘ ˘ l ü ˘
0032
1032
2032
LP1 Mains phase failure (from operating system V2.0)
l C0599 < 65535: LP1−TRIP
l C0599 = 65535: LP1 warning/LP1 message
C0599 ü l ü ü ˘
0050 OH Device heatsink temperature > 90 °C ü l ˘ ˘ ˘
0051 OH1 Internal device temperature > 90 °C ü l ˘ ˘ ˘
0053 OH3 Overload of external brake resistor l ˘ ˘ ˘ ˘
0061 CE0 Communication error on the automation interface (AIF) C0126 ü ˘ ˘ ˘ l
0062 CE1 Communication error at the process data input object CAN1_IN in cyclic operation
(sync−controlled)
l The monitoring time can be set via C0357/1.
ü ü ˘ ˘ l
0063 CE2 Communication error at the process data input object CAN2_IN in
event−controlled/cyclic operation without sync
l The monitoring time can be set via C0357/1.
ü ü ˘ ˘ l
0064 CE3 Communication error at the process data input object CAN3_IN in
event−controlled/cyclic operation without sync
l The monitoring time can be set via C0357/1.
ü ü ˘ ˘ l
0065 CE4 Bus−off status of the system bus (CAN)
(too many faulty telegrams or toggle bit errors)
C0595 ü l ˘ ˘ ü
0070 U15 Undervoltage of external low−voltage supply l ˘ ˘ ˘ ˘
0071 CCr System failure ü l ˘ ˘ ˘
0072 PR1 Checksum error in parameter set 1 ü l ˘ ˘ ˘
