Commissioning
After mains switch−on
Fault responses
6
68
EDBCSXE040 EN 6.0
6.6.3 Fault responses
Reaction ð Consequence
Display
Keypad XT
RDY IMP Fail
TRIP / Short−circuit
braking TRIP
o
n n
TRIP active: ð The charging of the DC bus is stopped. With short−circuit braking
TRIP the DC bus is quickly discharged via the brake resistor.
ð The drive is coasting (no control).
ð The system bus (CAN) indicates to the master that the power
supply module is not ready for operation.
TRIP is reset: ð The power supply module is ready for operation again.
ð The charging of the DC bus is continued.
Message
Danger!
The drive restarts automatically if the message is removed.
o n n
Message active: ð The charging of the DC bus is stopped.
ð The drive is coasting (no control).
ð The system bus (CAN) indicates to the master that the power
supply module is not ready for operation.
Message is reset: ð The power supply module is ready for operation again.
ð The charging of the DC bus is continued.
Warning
ð The failure is only displayed, the drive continues to run normally.
n o n
Off STOP!
The drive can be destroyed due to deactivated monitoring
functions.
˘ ˘ ˘
ð There is no response to the failure.
o = off n = on
