Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Description of the display elements
7
73
EDBCSXE040 EN 6.0
7.3.2 Description of the display elements
YZ
y
z
T
V
S
U
dABbc
p
SHPRG
Para
Code
Menu
0050
00
50.00_Hz
MCTRL-NOUT
0
1
3
4
5
6
7
8
2
9371BC002
Fig. 7−3 Keypad front view
Status displays
Display Meaning Explanation
Ready for operation
Pulse inhibit active Power outputs inhibited
Adjusted current limitation is exceeded in
motor mode or generator mode
Speed controller 1 within its limitation l Drive is torque−controlled
l Only active for operation with Lenze
devices of the 9300 series!
Active fault
Parameter acceptance
Display Meaning Explanation
Parameter is accepted immediately The device immediately operates with the
new parameter value.
SHPRG The parameter must be confirmed with
The device operates with the new
parameter value after being confirmed.
SHPRG When the controller is inhibited, the
parameter must be confirmed with
The device operates with the new
parameter value after the controller has
been released again.
None Display parameters Cannot be changed.
Active level
Display Meaning Explanation
Menu Active menu level l Selection of main menu and submenus
l No menu for ECSxE power supply
module
Code Active code level Selection of codes and subcodes
Para Active parameter level Change of parameters in the codes or
subcodes
None Active operating level Display of operating parameters
Short text
Display Meaning Explanation
Alphanumerical
Contents of the menus, meaning of the codes
and parameters
Display of C0004 in % and the active fault in
the operating level
