8.1.5 Addressing of the parameter and process data objects
The CAN bus system is based on a message−oriented data exchange between a transmitter
and many receivers. Thus, all nodes can transmit and receive messages at the same time.
The identifier in the CAN telegram ˘ also called COB−ID (Communication Object Identifier)
controls which node is to receive a transmitted message. With the exception of the
network management (NMT) and the sync telegram (Sync) the identifier contains the
node address of the drive besides the basic identifier:
Identifier (COB−ID) = basic identifier + adjustable node address (node ID)
The basic identifier for the ECSxE power supply module is preset ex works with the
following values:
Object
Basic identifier
dec hex
Network management (NMT) 0 0
Sync telegram 128 80
Process data channel to ECSxE in cyclic operation (sync−controlled)
(RPDO: CAN1_IN)
512 200
Process data channel from ECSxE in cyclic operation (sync−controlled)
(TPDO: CAN1_OUT)
384 180
Process data channel to ECSxE in event−controlled/cyclic operation without sync
(RPDO: CAN3_IN)
768 300
Process data channel from ECSxE in event−controlled/cyclic operation without
sync (TPDO: CAN3_OUT)
769 301
Parameter data channel 1 to ECSxE (SDO1) 1536 600
Parameter data channel 2 to ECSxE (SDO2) 1600 640
Parameter data channel 1 from ECSxE (SDO1) 1408 580
Parameter data channel 2 from ECSxE (SDO2) 1472 5C0
Node Guarding 1792 700
Note!
The "8.2.1 Setting of CAN node address and baud rate" chapter contains
information on
ƒ Setting of the node address ( 95).
ƒ Individual addressing ( 98).
