Commissioning
Commissioning steps (overview)
Control via digital inputs
6
60
EDBCSXE040 EN 6.0
6.1.3 Control via digital inputs
Note!
Follow the commissioning steps in the given order!
Setting Short description Detailed
information
Initial state:
l Basic settings completed.
l C0001 = 1
57
1. Set input X6/DI2 to HIGH. Output X6/DO1 is set to HIGH when the module
is ready for operation.
2. Set input X6/DI1 to HIGH. Charging process is started.
After some seconds the earth−fault test is complete and the DC bus is charged. The power
supply module is now ready for operation (status word 1, bit 0 = 1).
