9 Diagnostics
9.1 Diagnostics with Global Drive Control (GDC)
Different system values and fault messages can be read in the GDC parameter menu under
Diagnostics via the following codes:
Parameter
C0050
Designation
Mains voltage (V
rms
) between phases L1−L2
Data type: INTEGER_32
Index: 24525
dec
= 5FCD
hex
Display of the mains voltage (V
rms
) between phases L1 and L2
Display range (min. value | unit | max. value)
−16383 V 16383
Parameter
C0051
Designation
Mains voltage (V
rms
) between phases L2−L3
Data type: INTEGER_32
Index: 24524
dec
= 5FCC
hex
Display of the mains voltage (V
rms
) between phases L2 and L3
Display range (min. value | unit | max. value)
−16383 V 16383
Parameter
C0053
Designation
DC−bus voltage (U
G
)
Data type: INTEGER_32
Index: 24522
dec
= 5FCA
hex
Display of the DC−bus voltage (U
G
)
Display range (min. value | unit | max. value)
−32767 V 32767
Parameter
C0054
Designation
Mains current (r.m.s. value)
Data type: INTEGER_32
Index: 24521
dec
= 5FC9
hex
Display of the mains current (r.m.s. value)
Display range (min. value | unit | max. value)
−1638.3 A 1638.3
Parameter
C0055
Designation
Voltage across the brake resistor
Data type: INTEGER_32
Index: 24520
dec
= 5FC8
hex
Display of the voltage across the brake resistor
Display range (min. value | unit | max. value)
−32767 V 32767
Parameter
C0057
Designation
Mains frequency
Data type: INTEGER_32
Index: 24518
dec
= 5FC6
hex
Display of the mains frequency
Display range (min. value | unit | max. value)
−3276.7 Hz 3276.7
