25
Install memory and option cards
Installing
memory cards
Follow the instructions in this section to
install either a printer memory card or a
flash memory card. The system board
has three connectors for optional
memory cards. You can install any
combination of printer memory and flash
memory cards in the three connectors.
However, the printer only recognizes one
flash memory card at a time.
Note: Some memory options for other
Lexmark printers cannot be used with
your printer.
1 Access the system board. (See
page 24 for instructions.)
2 Locate the memory connectors on
the system board.
Each connector can support
either a printer memory card or a
flash memory card.
3 Push open the latches on both
ends of the connector you want to
use.
Memory connectors
Latches
jp_setup.book Page 25 Friday, February 16, 2001 7:42 AM
