71
Install the optional envelope feeder
Step 11: Install the optional
envelope feeder
CAUTION! If you are installing the
envelope feeder sometime after initial
printer setup, turn the printer off and
unplug the power cord before continuing.
The Lexmark W820 supports an optional
envelope feeder that lets you feed up to
100 envelopes automatically.
To install the envelope feeder:
1 Remove the envelope feeder from
its packaging.
Remove any plastic wrapping and
shipping tape.
Save the carton and packing
materials in case you need to
repack the envelope feeder.
2 Remove the multipurpose feeder
from the printer.
a Hold the multipurpose feeder
by both sides.
b Lift the multipurpose feeder
slightly and then pull it straight
out.
Warning! Pull both sides of the
multipurpose feeder out of the printer at
the same time.
jp_setup.book Page 71 Friday, February 16, 2001 7:42 AM
