LG 42LE8500 User Manual

BLUETOOTH
BLUETOOTH
104
MY BLUETOOTH INFORMATION
This function provides the My Bluetooth Information to the user.
"Edit" will be available when TV is not connected with any device.
You can edit the Setup TV PIN or Setup TV name.
You can check the TV address.
To accept connection from an external Bluetooth device or to connect to an external Bluetooth device,
the PIN needs to be entered.
For details on how to set the PIN of the external Bluetooth device, refer to the user manual of the
applicable device.
The TV PIN is composed of numbers of up to 16 digits.
The TV PIN must have more than 1 digit.
Bluetooth off
Search headset
ꕉ Exit
ꔅ My Infoꔅ Remove Device
ꔂ Move ꔉ Enter
Bluetooth
My Info
Close
Setup TV PIN. 0000
Setup TV name. GLOBAL-PLAT2
TV address 00:05:c9:51:06:f3
i
1
MENU
ENTER
Select BLUETOOTH.
2
BLUE
Select My Info.
3
Select Setup TV PIN or Setup TV name.
4
ENTER
12 ABC 3 DEF
4 GHI 5 JKL 6 MNO
7 PQRS 8 TUV
0
9
WXYZ
You can use an the alphabet A to Z,
the number 0 to 9, and blank.
5
ENTER
Save.
6
BACK
Return to the previous menu.
EXIT
Return to TV viewing.
Bluetooth off
Search headset
ꕉ Exit
ꔅ My Infoꔅ Remove Device
ꔂ Move ꔉ Enter
Bluetooth
PLT 510DR-BT140Q sgh-e760 No device
ꔛ
Press the DELETE button to delete
digits one by one.

LG 42LE8500 Specifications

General

Display diagonal	42 \
Product color	Black
Audio system	Dolby Digital Plus
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Power consumption (standby)	0.1 W
Power consumption (typical)	160 W
Annual energy consumption	138.23 kWh

Weight and Dimensions

Depth (with stand)	235.5 mm
Height (with stand)	704.5 mm
Weight (with stand)	27200 g
Depth (without stand)	34.5 mm
Width (without stand)	1013.3 mm
Height (without stand)	645.8 mm
Weight (without stand)	23000 g
