WATCHING TV / CHANNEL CONTROL
WATCHING TV / CHANNEL CONTROL
90
ꔛ
When new external device is connected, this popup
menu is displayed automatically.
If selecting Yes, you can select input source that you
want to appreciate.
ꔛ
But, when selecting “SIMPLINK - On”, popup menu for
HDMI input will not be displayed.
INPUT LIST
Only these input signals which are connected to a TV can be activated and selected.
1
INPUT
ENTER
Select the desired input source.
ꔛ
You can also select the desired input source in the INPUT menu.
ꔛ
TV: Select it to watch over-the-air, cable and digital cable broadcasts.
ꔛ
USB: Select it to use movie, photo, or music files.
ꔛ
AV: Select them to watch a VCR or other external equipment.
ꔛ
Component: Select them to watch DVD or a Digital set-top box.
ꔛ
RGB-PC: Select it to view PC input.
ꔛ
HDMI: Select them to watch high definition devices.
No
Yes
New external input is connected.
Do you want to use this?
AV1
Input List
ꔂ Move ꔉ Enter
TV USB1 USB2 AV 1 AV 2 Component1
Component2 Component3 RGB-PC HDMI1 HDMI2 HDMI3
ꔅ Input Label ꕉ Exit
Disconnected inputs are inactive
(grayed out)
i.e)

LG 42LE8500 Specifications

General

Display diagonal	42 \
Product color	Black
Audio system	Dolby Digital Plus
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Power consumption (standby)	0.1 W
Power consumption (typical)	160 W
Annual energy consumption	138.23 kWh

Weight and Dimensions

Depth (with stand)	235.5 mm
Height (with stand)	704.5 mm
Weight (with stand)	27200 g
Depth (without stand)	34.5 mm
Width (without stand)	1013.3 mm
Height (without stand)	645.8 mm
Weight (without stand)	23000 g
