LG 42LE8500 User Manual

PREPARATION
PREPARATION
22
STAND INSTRUCTIONS (For 50/60PK550, 50/60PK950, 50/60PX950)
ꔛ
Image shown may differ from your TV.
INSTALLATION (For 50PK550) INSTALLATION (For 50PK950, 50PX950)
!
NOTE
► When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
3
Assemble the parts of the CABLE
MANAGEMENT CLIP with the STAND
BODY.
3
Assemble the TV as shown.
4
Assemble the TV as shown.
4
Fix the 4 screws securely using the holes
in the back of the TV.
5
Fix the 4 screws securely using the holes
in the back of the TV.
STAND BASE
STAND BASE
STAND BODY
STAND BODY
STAND BODY
CABLE
MANAGEMENT
CLIP
M5 x 14
M4 x 14
M4 x 28
M4 x 28

LG 42LE8500 Specifications

General

Display diagonal	42 \
Product color	Black
Audio system	Dolby Digital Plus
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Power consumption (standby)	0.1 W
Power consumption (typical)	160 W
Annual energy consumption	138.23 kWh

Weight and Dimensions

Depth (with stand)	235.5 mm
Height (with stand)	704.5 mm
Weight (with stand)	27200 g
Depth (without stand)	34.5 mm
Width (without stand)	1013.3 mm
Height (without stand)	645.8 mm
Weight (without stand)	23000 g
