Linksys X2000 User Manual

7
Installation
Linksys X2000/X3000
Or, if you chose Router only in Step 4:
a. Connect the power cable, then turn on the power switch.
b. Connect the blue cable to the Cable port on the back of your router
and to the modem.
6. If you chose Modem router in Step 4, you are asked to enter your ISP
information.
a. Select your region, ISP, and the DSL settings your ISP has provided.
b. Select your Internet connection type, other Internet settings, and
static settings (if necessary). All of this information should be available
from your ISP.
7. Follow the on-screen instructions to finish the setup.
Set up your modem-router manually
NOTE
Run the Setup CD-ROM to install the modem-router. If you cannot
run the Setup CD-ROM, refer to the steps below.
NOTE
If you are setting up your modem-router in New Zealand, see
“NOTE FOR USERS IN NEW ZEALAND” on page 9.

Linksys X2000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11a, 802.11b, 802.11g
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Dimensions (WxDxH)	245 x 67 x 273 mm
Minimum system requirements	IE 7.0 Safari 4 Firefox 3
Compatible operating systems	Windows XP SP3 Windows Vista SP1 Windows 7 Mac OS X Leopard 10.5 Mac OS X Snow Leopard 10.6
Web-based management	No
Ethernet LAN (RJ-45) ports	3
Security algorithms	WPA, WPA2
Product color	Black

Weight and Dimensions

Weight	- g
