Linksys X2000 User Manual

26
Specifications
Linksys X2000/X3000
26
X3000
Standards WLAN: 802.11n, 802.11g, 802.11b
Ethernet: 802.3, 802.3u, 802.3ab
ADSL: T1.413i2, G.992.1 (G.DMT), G.992.2
(G.Lite), G.992.3 (ADSL2), G.992.5 (ADSL2+)
for Annex A, B, M, L, U-R2 for Annex B
USB 2.0
Ports DSL, Cable, Gigabit (10/100/1000) Ethernet (1-4),
Power, USB
Buttons On/O, Reset, Wi-Fi Protected Setup™
LEDs Power, Ethernet (1-4), Wi-Fi Protected Setup,
Wireless, Internet
Cabling Type CAT5, RJ-11 (for Annex A), RJ-45 (for Annex B)
Antennas 2 Internal
Modulations 802.11b: CCK/QPSK, BPSK
802.11g: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
802.11n: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
Transmit Power 802.11b: 12,5 ± 1,5 dBm
802.11g: 12,5 ± 1,5 dBm
802.11n: 12,5 ± 1,5 dBm
Receive Sensitivity 802.11b: -85 dBm (typical) @ 11 Mbps
802.11g: -70 dBm (typical) @ 54 Mbps
802.11n HT20: -68 dBm (typical) @ MCS15
802.11n HT40: -65 dBm (typical) @ MCS15
Antenna gain 802.11b/g/n: Right antenna 3,60 dBi
Left antenna 2,51 dBi
Security Features WPA2™/WPA™ Personal and Enterprise;
128, 64 bits WEP; MAC Address Filtering;
SPI Firewall
OS Requirements Windows 7, Windows Vista, Windows Vista
(for Setup wizard) 64-bit edition, or Windows XP
Mac OS X 10.5 or higher
USB Storage Maximum supported capacity: 1 x 2 TB
Environmental
Dimensions 202 x 34 x 160 mm (8,0” x 1,3” x 6,3”)
Weight 335 g (11,8 oz)
Power 12VDC, 1,5A
Certication FCC, CE, Telepermit, K.21, UL, CB,
Wi-Fi (802.11b/g/n), WPA™, WPA2™, WMM,
Wi-Fi Protected Setup™
Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -20 to 70°C (-4 to 158°F)
Operating Humidity 10 to 85% Noncondensing
Storage Humidity 5 to 90% Noncondensing
NOTES
For regulatory, warranty, and safety information, see the CD that
came with your modem router or go to Linksys.com/support.
Specifications are subject to change without notice.
Maximum performance derived from IEEE Standard 802.11
specifications. Actual performance can vary, including lower
wireless network capacity, data throughput rate, range and
coverage. Performance depends on many factors, conditions and
variables, including distance from the access point, volume of
network traffic, building materials and construction, operating
system used, mix of wireless products used, interference and other
adverse conditions.

Linksys X2000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11a, 802.11b, 802.11g
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Dimensions (WxDxH)	245 x 67 x 273 mm
Minimum system requirements	IE 7.0 Safari 4 Firefox 3
Compatible operating systems	Windows XP SP3 Windows Vista SP1 Windows 7 Mac OS X Leopard 10.5 Mac OS X Snow Leopard 10.6
Web-based management	No
Ethernet LAN (RJ-45) ports	3
Security algorithms	WPA, WPA2
Product color	Black

Weight and Dimensions

Weight	- g
