LTH Electronics MXD75 User Manual

Registers
- 54 -
Modbus RS485 Interface
Operating Guide
Registers
Conventional Conductivity Input Calibration
Conventional Conductivity Input Calibration
6550 Get/Set Channel 1 Cal Access INT Front Screen Calibration
Access
1076 = Yes
6930 Channel 2 1077 = No
7310 Channel 3
6551 Get/Set Channel 1 Cal Manual
Temperature
Input*
FLOAT Calibration Manual
Temperature Input
*(Only available when
Temperature
compensation Mode is
set to Manual)
-20.0°C to 150.0°C
6931 Channel 2 -4.0°F to 302.0°F
7311 Channel 3
6553 Get Channel 1 Reading Slope FLOAT Sensor Slope Value 90 to 110%
6933 Channel 2
7313 Channel 3
6555 Get Channel 1 Temperature
Offset*
FLOAT Temperature Offset
Value
*(Not available when
Temperature Sensor is set
to Disabled)
-25°C to +25°C
-13.0°F to 77.0°F
6935 Channel 2
7315 Channel 3
6557 Get/Set Channel 1 Calibration
reminder
INT Calibration Reminder 1076 = Yes
6937 Channel 2 1077 = No
7317 Channel 3
6558 Get/Set Channel 1 Calibration
Interval*
FLOAT Calibration Interval
Value
*(Only available when
Calibration Reminder set
to yes)
0 to 999 Days
6938 Channel 2
7318 Channel 3
6560 Get/Set Channel 1 Calibration
Alarm Date*
INT Calibration Alarm Date
Value
*(Only available when
Calibration Reminder set
to yes)
1 to 31 Day
6940 Channel 2
7320 Channel 3
6561 Get/Set Channel 1 Calibration
Alarm Month*
INT Calibration Alarm
Month Value
*(Only available when
Calibration Reminder set
to yes)
1 to 12 Month
6941 Channel 2
7321 Channel 3
6562 Get/Set Channel 1 Calibration
Alarm Year*
INT Conductivity Calibration
Alarm Year Value
*(Only available when
Calibration Reminder set
to yes)
Max 2099 Year
6942 Channel 2
7322 Channel 3
