Registers
Modbus RS485 Interface
Operating Guide
- 77 -
Registers
Data Logging Configuration
Register
#
Access
Rule
Name Data
Format
Description of
Attribute
Semantics of Values
SD Card Data logging Configuration
10500
Get Status INT Data logging Status 1076 = Logging Data
1077 = Not Logging Data
10501 Get/Set Interval Hours INT Data logging Interval
(Hours)
0 to 23 Hours
10502 Get/Set Interval Minutes INT Data logging Interval
(Minutes)
0 to 59 Minutes
10503 Get/Set Interval Seconds INT Data logging Interval
(Seconds)
0 to 59 Seconds
10504 Get/Set Data log Channel 1 INT Channel 1 Log 1695 = Enabled
1696 = Disabled
10505 Get/Set Data log Range 1* INT Channel 1 Range
*(Only available when
the range of the Input
Channel is set to Auto)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10506 Get/Set Data log Channel 2 INT Channel 2 Log 1695 = Enabled
1696 = Disabled
10507 Get/Set Data log Range 2* INT Channel 2 Range
*(Only available when
the range of the Input
Channel is set to Auto)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10508 Get/Set Data log Channel 3 INT Channel 3 Log 1695 = Enabled
1696 = Disabled
10509 Get/Set Data log Range 3 INT Channel 3 Range
*(Only available when
the range of the Input
Channel is set to Auto)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10510 Get/Set Data logging Calculation 1 INT Calculation 1 Log 1695 = Enabled
1696 = Disabled
10511 Get/Set Calculation 1 Range* INT Calculation 1 Range
*(Only available when
the channels associated
with the calculation been
set to Auto Range )
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10512 Get/Set Data logging Calculation 1 INT Calculation 2 Log 1695 = Enabled
1696 = Disabled
10513 Get/Set Calculation 2 Range* INT Calculation 2 Range
*(Only available when
the channels associated
with the calculation been
set to Auto Range )
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
10514 Get/Set Loop Recording INT Loop recording 1076 = Enabled
1077 = Disabled
To Next Page
