Manitou MHT 7140 T-E3 User Manual

5-8
TECHNICAL SPECIFICATIONS OF ATTACHMENTS
FLOATING FORK CARRIAGE
MHT 7140 T-E3-
PF FLOTT / L 1750 PF FLOTT / L 2000
PART NUMBER 607552 607924
Rated capacity 16000 kg 16000 kg
Width 1900 mm 2090 mm
Weight 680 kg 795 kg
FLOATING FORK SIDE-SHIFT CARRIAGE
- MHT 7140 T-E3-
TDL FL / 600-2200 TDL FL / 550-2545
PART NUMBER 710195 724189
Rated capacity 10000 kg 8000 kg
Lateral displacement 2x200 mm 2x200 mm
Width 2600 mm 2600 mm
Weight 1310 kg 1310 kg
FLOATING FORK
MHT 7140 T-E3-
PART NUMBER 606842 716883 731985
Section 200x80x1500 mm 200x80x1500 mm 200x80x1800 mm
Weight 270 kg 270 kg 330 kg
FLOATING FORK
MHT 7140 T-E3-
PART NUMBER 719370 688975 675311
Section 200x80x2400 mm 200x80x2400 mm 200x80x2500 mm
Weight 400 kg 270 kg 350 kg
