SERVICING SCHEDULE
(1): MANDATORY 500 HOUR OR 6 MONTH SERVICE
This service must be carried out after approximately the first 500 hours of operation or within the 6 months following the start-up of the machine (whichever
occurs first).
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS SERVICE
EVERY 50 HOURS
SERVICE
EVERY 250 HOURS
SERVICE
EVERY 500 HOURS
SERVICE OR 6
MONTHS
EVERY 1000 HOURS
SERVICE OR 1 YEAR
EVERY 2000 HOURS
SERVICE OR 2 YEARS
EVERY 4000 HOURS
SERVICE
OCCASIONALLY
I.C. ENGINE
I.C. engine oil level
3-12 C C <<< <<< <<< <<< <<< <<<
Cooling liquid level 3-12 C C <<< <<< <<< <<< <<< <<<
Fuel level 3-13 C C <<< <<< <<< <<< <<< <<<
Fuel pre-filter 3-13 C C <<< <<< <<< <<< <<< <<<
Dry air filter cartridge 3-18/29 R C/N <<< R <<< <<< <<<
Radiator cores 3-18 N N <<< <<< <<< <<< <<<
Condenser core (OPTION Air conditioning) 3-24 C/N C/N <<< <<< <<< <<< <<<
Alternator/crankshaft belt tension 3-26 C/A C/A <<< <<< <<< <<<
I.C. engine oil 3-26 V V <<< <<< <<<
I.C. engine oil filter 3-29 R R <<< <<< <<<
Fuel pre-filter 3-29 R R <<< <<< <<<
Fuel filter 3-33 R R <<< <<< <<<
Fuel tank 3-33 N <<< <<<
Safety dry air filter cartridge R <<< <<<
I.C. engine silent blocks C** <<< <<<
I.C. engine rates 3-28 C** <<< <<<
Valves clearances 3-36 C** C** <<< <<<
Cooling liquid 3-36 V <<<
Radiator C** <<<
Water pump and the thermostat C** <<<
Alternator and the starter motor C** <<<
Turbocompressor C** <<<
Fuel system P
TRANSMISSION
Gear box oil level
3-25 C C <<< <<< <<< <<< <<< <<<
Oil filter transmission 3-19 R R <<< <<< <<<
Gear box oil 3-31 V V <<< <<<
Silentblocks in the gear box 3-34 C** <<< <<<
TYRES
Tyres pressure
3-14 C C <<< <<< <<< <<< <<< <<<
Wheel nuts torque 3-14 C C <<< <<< <<< <<< <<< <<<
Condition of wheels and tyres C** <<< <<<
Wheel 3-38 R
BOOM
Boom pads
3-14 G* <<< <<< <<< <<< <<< <<<
Boom 3-20 G G <<< <<< <<< <<< <<<
Boom pads wear C** <<< <<<
Condition of boom unit C** <<<
Bearings and articulation rings C** <<<
HYDRAULIC
Hydraulic oil level
3-21 C C <<< <<< <<< <<< <<<
Hydraulic return oil filter cartridge 3-31 R R <<< <<< <<<
Hydraulic oil 3-34 V <<< <<<
Suction strainer for hydraulic oil tank 3-34 N <<< <<<
Filter cap for hydraulic oil tank 3-34 R <<< <<<
Speeds of hydraulic movements C** <<< <<<
Condition of hoses and flexible pipes C** <<< <<<
Condition of cylinders (leakage, shafts) C** <<< <<<
Hydraulic circuit pressures C** <<<
Hydraulic circuit outputs C** <<<
Hydraulic oil tank N** <<<
