Manitou MHT 7140 T-E3 User Manual

2-8
CHARACTERISTICS
MHT 7140 T-E3
I.C. ENGINE
Type MERCEDES-BENZ (OM 904 LA)
Fuel Diesel
Number of cylinders 4 in line
Suction Supercharged
Injection system Direct
Ignition sequence 1,3,4,2
Capacity cm3 4250
Bore and stroke mm 102 x 130
Compression ratio 18:1
Nominal rating loaded rpm 2200
Rating slow unladen rpm 800
Max. rating unladen rpm 2400
Power ISO/TR 14396 cv- kW 175 - 129
Power SAE J 1995 cv- kW 175 - 129
Maximum torque ISO/TR 14396 Nm 675 Nm from 1200 to 1600 rpm
Air cleaner μm3
Type of cooling By water
Fan Puller
TRANSMISSION
Gear box DANA
Type
Meccanic, with differential block and hydraulic
control
Forward/reverse selector Electromagnetic
Number of forward speeds 2
Number of reverse speeds 2
Hydrostatic pump REXROTH
Type
A4VG125DA Hydrostatic with continuous
speed adjustment and engine with inching
Main pump
displacement min./max. cm
3
/giri 0 a 125
Capacity max. L/min. 285
Pressure bar 465
Supply pump
displacement cm
3
28,3
Capacity max. L/min. 65
Pressure bar 32 ±2
Hydrostatic motor REXROTH
Type A6VM160DA
displacement min./max. cm
3
/giri 75 a 160
Front axle OMCI Heavy duty
Differential NO Limited slip
Reduction gear Planetary gear
Rear axle OMCI Heavy duty
Reduction gear Planetary gear
Drive wheels 4RM Permanent
Front tyres MICHELIN
Size 16.00 (445/95) R25 XLB 177E
Pressure bar 9
Rear tyres MICHELIN
Size 16.00 (445/95) R25 XLB 177E
Pressure bar 9
ELECTRIC CIRCUIT
Battery Standard 12 V - 120 Ah - 850 A EN
Alternator 14 V - 90 ÷ 150 A
Starter 12 V - 3,2 kW
BRAKE CIRCUIT
Service brake Hydraulic power brake
Type of brake Multidisk brake immersed in oil
Type of control Foot-operated for the front and rear axles
Parking brake
Type of brake
Negative action, acts on front and rear axle
service brakes
Type of control Electro-hydrailc
