Manitowoc Grove RT9130E-2 Service And Maintenance Manual

Grove Published 11-22-2016, Control # 345-12 1-5
RT9130E-2 SERVICE MANUAL INTRODUCTION
1
Table 1-1
Axle Weight Distribution Table
Description
CG to CL Bogie
in (cm)
Weight
lb (kg)
Front Axle
lb (kg)
Rear Axle
lb (kg)
Basic Unit
Maximum Axle Loads Allowed 90000 (40824) 90000 (40824)
Maximum Tire Loads Allowed 90000 (40824) 90000 (40824)
Carrier 4 x 4; All Fluids 83.50 (212.1) 53202 (24132) 22840 (10360) 30362 (13772)
Front Outrigger Box and Beam Assembly 266.00 (675.6) 9427 (4276) 12892 (5848) -3465 (-1572)
Rear Outrigger Box and Beam Assembly -82.00 (-208.3) 9427 (4276) -3974 (-1803) 13401 (6079)
Superstructure w/cab plus w/main hoist plus
950 ft cable; less counterweight plus lower
lift pin
42.69 (108.4) 14786 (6707) 3245 (1472) 11541 (5235)
Removable Counterweight (includes
cylinders, aux hoist and cables)
-56.47 (-143.4) 28084 (12739) -8154 (-3698) -36238 (-16437)
Boom Assembly; w/RCL, 2/7 Nose Sheaves,
Pivot Pins
260.55 (661.8) 33482 (15187) 44852 (20345) -11370 (-5158)
Lift Cylinder 213.50 (542.3) 3900 (1769) 4281 (1942) -381 (-173)
Complete Basic Machine
4 x 4 chassis; Cummins QSC8.3 300 Tier 3
engine w/ transmission; front and rear axles;
33.25 x 29 tires; main hoist
w/289 m (950 ft) of 3/4 in. cable; full fuel and
hydraulic oil; RCL; plus all the above.
97.03 (246.5) 152308 (69086) 75983 (34466) 76325 (34620)
Add To Basic Unit Weight
10.97 to 17.98 m (36 to 59 ft)
Bi-Fold Boom Extension
295.25 (749.9) 3110 (1411) 4721 (2141) -1611 (-730)
10.97 meter (36 ft) Fixed Boom Extension 329.56 (837.1) 2300 (1043) 3897 (1768) -1597 (-725)
10.97 to 17.98 m (36 to 59 ft) Bi-Fold
Hydraulic Boom Extension
317.00 (805.2) 3516 (1595) 5730 (2599) -2214 (-1004)
10.97m (36 ft) Fixed Hydraulic Boom
Extension
351.83 (893.6) 2722 (1235) 4924 (2234) -2202 (-999)
Components for Hydraulic Boom Extension 368.65 (936.4) 202 (92) 383 (174) -181 (-82)
Boom Ext. Carrier Brackets (Bolt On) 238.62 (606.1) 220 (100) 270 (122) -50 (-22)
Auxiliary Boom Nose - Installed 530.00 (1346.2) 125 (57) 341 (155) -216 (-98)
72 mt (80 Ton), 7 Sheave Hookblock -
Stowed in trough
185.00 (469.9) 1600 (726) 1522 (690) 78 (36)
118 mt (130 Ton), 8 Sheave Hookblock -
Stowed in trough
185.00 (469.9) 2530 (1147) 2406 (1091) 124 (56)
9.0 mt (10 Ton), Headache Ball (Swivel)-
Attached to O/R Box
310.00 (787.4) 680 (308) 1084 (491) -404 (-183)
Driver 92.00 (233.7) 250 (113) 118 (53) 132 (60)
Rear Mounted Pintle Hook -83.50 (-212) 30 (14) -13 (-6) 43 (20)
Boom Removal Kit 236.66 (601.0) 85 (39) 103 (47) -18 (-8)
