Mercury Optimax 175 User Manual

DIRECT FUEL INJECTION
90-855347R1 JANUARY 1999 Page 3B-7
Air Handler
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 COVER ASSEMBLY
2 2 GROMMET
3 1 AIR FILTER
4 1 COVER
5 1 RIVET
6 1 RETAINER
7 1 GROMMET
8 1 GROMMET (150)
9 1 GROMMET (135)
10 1
AIR HANDLER ASSEMBLY
(See Breakdown on Air Handler Components)
11
1 SHIM (.020 THICK)
11
1 SHIM (.010 THICK)
12 1 DECAL-Caution-Start in Gear
13 1 BRACKET
14 1 SLEEVE
15 4 SCREW (M6 x 16) 100 11.5
16 1 FUEL PUMP
17 4 CLAMP
18 1 HOSE
19 1 TUBING (18 IN.)
20 1 INSULATING SLEEVE
21 1 ELBOW
22 1 FITTING
23 1 O RING
24 1 GROMMET
25 1 ENCODER
26 1 SCREW (10-24 x 5/8 IN.) Drive Tight
27 1 WASHER
28 2 J CLAMP (Upper Stbd.)
29 1 CLAMP-(Lower)
30 12 SCREW (1/4-20 x 1-1/2 IN.) 175 15 20
31 1 TUBING (5-3/4 IN.)
32 1 CANISTER-Vent
33 3 STA STRAP
34 1 CONNECTOR
35 1 PIN
36 1 DECAL EPA LABEL (1999) (SEE NOTE)
37 1 CABLE TIE (14 IN.)
38 1 CABLE
39 1 WASHER
40 1 WASHER
NOTE: THE EPA LABEL HAS IMPORTANT INFORMATION ON EPA EMISSION REGULATIONS. REPLACE ANY
MISSING OR UNREADABLE EPA LABEL.
