Section 3 - Screen Overview and Operation
90-8M0087257 eng DECEMBER 2014 Page 31
When all targets have been achieved, the user‑selected data area screen will change from instructions, to displaying
OPTIMIZED with the current fuel economy value.
ECO Navigation
The user‑selected data area footer will display REFRESH, MINIMIZE, and X. Use the pages, arrow, and enter buttons to
navigate these features.
• Minimize will hide ECO instructions and display ECO MODE in the system status field. Minimize allows the user to display
other information in the user‑selected data area.
• Refresh will reset the ECO values and use new parameters for determining the RPM and trim target values.
• X will close ECO mode, removing the RPM and trim targets from the constant data area.
• The active area will have a white border.
a - Refresh
b - Minimize feature active
c - Exit
ECO Refresh
Refresh allows you to recalculate the current values that ECO uses for the RPM and trim targets.
1. Use the arrow buttons to highlight the refresh feature and press enter.
2. Instructions appear in the user‑selected data area. Use the arrow button to highlight the refresh feature and press enter.
3. When the system has finished calculating new targets, the user‑selected data area will change to indicate that the values
have been refreshed.
