Technical Information
G600 & G800 Electronic Dishwashers
4.14 Water Intake
If the water pressure is low, the electronic can be programmed to
increase the allotted intake duration from 2 minutes, to up to 4 minutes.
For further information refer to the section 6 Fault Diagnosis.
1 Input - Ion exchanger (softener)
2 Intake opening - Sump
3 Output - Ion exchanger (softener)
4 Water softener selector
5 Bypass - Water
6 Non-return device
7 Water reservoir
8 Water intake channel
9 Cabinet ventilation
10 WaterProof system (valve Y2)
11 Salt container
12 Solenoid valve Y38/1
13 Non-return valve
14 Ion exchanger
Figure 4-9: Water Intake System Equipped With Integrated Flowmeter
37
