Technical Information
G600 & G800 Electronic Dishwashers
5.25 WaterProof System (WPS) Restrictor - Exchange
1. Shut off the water supply.
2. Disconnect the WPS at the plumbing supply connection.
3. Remove the Sealing Washer and Filter from inside the WPS
connection
4. Using a 5mm nut-driver; press and tilt the Restrictor to the side; as
shown in figure 5-23.
Figure 5-23: Tilting the Flow Restrictor
5. Remove the Restrictor with needle-nose pliers; as shown in figure
5-24.
Figure 5- 24: Removing the Flow Restrictor.
6. Fit the new Restrictor using a suitable 5 mm socket spanner.
Service Tip
Use care when installing a new Flow Restrictor, a damaged
Restrictor should never be used.
77
