Technical Information
G600 & G800 Electronic Dishwashers
5.3 Side Panel - Removal
Figure 5-3: Side Panels and Cabinet
Refer to figure 5-3
With the appliance removed from it’s installation location
2. Remove the raised head screws (Items 1 and 3).
3. Open the Door.
4. Remove the Raised Head Screws, (Item 2).
5. Remove the Side Panels.
Service Tip
When reinstalling the Side Covers; fit the bottom lip of the panel into
the edge of the Drip Tray.
58
