G600 & G800 Electronic Dishwashers
5.32 Steam Condenser - Removal
1. Remove the Left Side Panel (5.3).
2. Open the Door.
3. Unscrew the Top Air Duct Cap (Intake Connection).
4. Unscrew the Bottom Air Duct Cap from the Steam Condenser
(Bayonet Connection).
5. Remove the Top Air Duct.
6. Unclip the Steam Condenser from the frame.
7. Disconnect the Hose Connections.
8. Disconnect the Fan Plug.
9. Unscrew the Heating Relay Fixing Screw. Remove the Heating
Relay.
1 Water Control ValveY6 – (for Steam Condenser)
2 Fan M2
3 Vent / Water Port from condenser
4 Steam Condenser Assembly
5 Air Duct (Condenser Intake)
6 Water Intake Assembly
7 Solenoid Valve Y5 - Water hardness
8 Cabinet Vent / Water Port (un-softened)
9 Flow Meter B3/4
10 Reactivation Valve Y38
11 Water Softener Assembly
Figure 5-27: Steam Condenser Components
