Technical Information
G600 & G800 Electronic Dishwashers
The sensor is located within the plumbing connection between the
Circulation Pump and Top Spray Arm. In order to compensate for
residues on the sensor and ageing of the optical system, the Turbidity
Sensor is re-calibrated automatically every time the dishwasher runs a
program (the steps on the Timing Chart are marked with a “T “). To
prevent residues drying on the sensor surface, the sensor remains in
water after the drainage cycle.
4.25 Electronic Unit - Power Outputs
The Electronic Unit controls all components within the dishwasher.
The activation of components requiring 120VAC power is handled by
Thyristors and Relays within the Electronic. The individual components
of the Electronic are not replaceable. Should the Electronic require
replacement; the Electronic is replaced as one assembled component.
Table 4-9: Activation of components
55
