Technical Information
G600 & G800 Electronic Dishwashers
5.8 Combination Dispenser - Removal
Figure 5-11: Exterior view of the Inner Door Panel
1. Remove the Outer Door Panel (5.10).
2. Disconnect all Electrical Plugs; and Hose – if fitted with a Fan.
Service Tip
To help avoid incorrect connection, the plug connection leads are of
different lengths.
3. Remove the Raised Head Screws (Figure 11 – Item 1).
4. Press the Retaining Clips downwards in the direction of the arrow
(Figure 11), and remove the Combination Dispenser Unit.
5. Fit a new Combination Dispenser Unit.
6. On models without a Fan, fit a stopper in the connection for the
Condensate Hose.
7. Check for proper operation.
64
