Miele H 2861 BP User Manual

Cleaning and care
65
Door removal
The door weighs approx. 10kg.
The oven door is connected to the door
hinges by retainers.
Before removing the door from the
retainers, the locking clamps on both
door hinges have to be released.
 Open the door fully.
 Release the locking clamps by
turning them as far as they will go.
The oven could become damaged if
you incorrectly remove the door.
Never pull the door horizontally off its
retainers, as they will spring back
against the oven.
Never pull the door off the retainers
by the handle, as the handle could
break off.
 Raise the door up till it rests partially
open.
 Hold the door on either side and pull
it diagonally upwards off the
retainers. Make sure that the door
goes back on straight.

Miele H 2861 BP Specifications

General

Grill	Yes
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Cord length	1.5 m
Control type	Rotary
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Control panel material	Glass
Clock type	Electronic
Timer type	Digital
Timer modes	Cooking time
Current	16 A
Connected load	3600 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	0.71 kWh
Energy consumption (forced convection)	1.1 kWh
Lamp type	Halogen
Lamps quantity	1 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	595 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	590 mm
