Installation
*INSTALLATION*
80
Electrical connection
 Danger of injury!
Installation, repairs and other
maintenance work by unqualified
persons could be dangerous. Miele
cannot be held liable for
unauthorised work.
The appliance may only be connected
to the mains electricity supply by a
qualified electrician who is familiar
with and complies with the national
regulations and any additional
regulations of the local electricity
provider.
The appliance must be connected to an
electrical system designed in
accordance with VDE0100.
Connection to a switched socket (in
accordance with VDE0701) is
recommended as this provides easier
access in the case of a service call.
If the appliance is hardwired or if the
plug is not accessible, an additional
means of disconnection must be
provided for all poles.
Suitable means of disconnection include
switches with an all-pole contact gap of at
least 3mm. These include circuit
breakers, fuses and contactors
(EN60335).
Connection data is given on the data
plate situated at the front of the oven
compartment. Please ensure the
connection data matches the
household supply.
When contacting Miele, please quote
the following:
- Model identifier
- Serial number
- Connection data (mains voltage/
frequency/maximum rated load)
When replacing the cable supplied
with another cable or changing the
connection, only cable type
H05VV-F with a suitable cross-
sectional area (CSA) may be used.
Temporary or permanent operation on
an autonomous power supply system or
a power supply system that is not
synchronised with the mains power
supply (e.g. island networks, back-up
systems) is possible. A prerequisite for
operation is that the power supply
system complies with the specifications
of EN50160 or an equivalent standard.
The function and operation of the
protective measures provided in the
domestic electrical installation and in
this Miele product must also be
maintained in isolated operation or in
operation that is not synchronised with
the mains power supply, or these
measures must be replaced by
equivalent measures in the installation.
As described, for example, in the
current version of VDE-AR-E2510-2.

Miele H 2861 BP Specifications

General

Grill	Yes
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Cord length	1.5 m
Control type	Rotary
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Control panel material	Glass
Clock type	Electronic
Timer type	Digital
Timer modes	Cooking time
Current	16 A
Connected load	3600 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	0.71 kWh
Energy consumption (forced convection)	1.1 kWh
Lamp type	Halogen
Lamps quantity	1 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	595 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	590 mm
