Miele H 2861 BP User Manual

Notes for test institutes
94
Energy efficiency class according to EN60350-1
The energy efficiency rating is determined in accordance with EN60350-1.
Energy efficiency rating:A+
Please observe the following when conducting testing:
- Testing is undertaken using the Eco Fan heatfunction.
- Only accessories that are required for testing should be in the oven
compartment during tests.
Do not use other accessories that might be available such as FlexiClip runners
or catalytic enamelled panels such as side panels or roof liners.
- An important pre-condition for determining the energy efficiency rating is that
the door is tightly shut during testing.
Depending on measurement devices used, the functioning of the door seal can
be affected to a greater or lesser extent. This has a negative impact on the test
results.
Pushing against the door will compensate for this. In certain unfavourable
circumstances, suitable technical aids may also be necessary for this. This does
not occur in normal use.
Data sheet for household ovens
In acc. with delegated regulation (EU) No. 65/2014 and regulation (EU) No.
66/2014
MIELE
Model name/identifier H2465BP, H2467BP,
H2761BP, H2766BP,
H2861BP, H2761-1BP,
H2766-1BP, H2861-1BP
Energy efficiency index/cavity (EEI
cavity
) 81,7
Energy efficiency class/cavity
A+++ (most efficient) to D (least efficient) A+
Energy consumption per cycle for each cavity in conventional mode 1,10 kWh
Energy consumption per cycle for each cavity in fan-forced convection
mode
0,71 kWh
Number of cavities 1
Heat source(s) per cavity electric
Volume of cavity 76 l
Mass of the appliance 47,0 kg

Miele H 2861 BP Specifications

General

Grill	Yes
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Cord length	1.5 m
Control type	Rotary
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Control panel material	Glass
Clock type	Electronic
Timer type	Digital
Timer modes	Cooking time
Current	16 A
Connected load	3600 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	0.71 kWh
Energy consumption (forced convection)	1.1 kWh
Lamp type	Halogen
Lamps quantity	1 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	595 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	590 mm
