Miele H 2861 BP User Manual

Installation
*INSTALLATION*
81
Oven
The wires in the mains lead are
coloured as follows:
Green/yellow = earth
Blue = neutral
Brown = live
 WARNING - THIS APPLIANCE
MUST BE EARTHED
For extra safety it is advisable to protect
the appliance with a suitable residual
current device (RCD).
Maximum connected load: see data
plate.
Electrical connection: Other
countries
All electrical work should be carried out
by a suitably qualified and competent
Miele approved service technician in
strict accordance with local and
national safety regulations.
Connection should be made via a fused
connection unit or a suitable isolator,
which complies with national and local
safety regulations, and the on/off switch
should be easily accessible after the
appliance has been installed.
If the switch is not accessible after
installation (depending on country) an
additional means of disconnection must
be provided for all poles.
Switches with a minimum all-pole
contact gap of 3mm are suitable for
isolating the appliance. These include
circuit breakers, fuses and protective
devices.
The voltage and rated load are given on
the data plate situated at the front of
the oven interior. Please ensure that
these match the household mains
supply.
For extra safety it is advisable to install
a suitable residual current device
(RCD) / ground fault interrupter (GFI).
Contact a qualified electrician for
advice.
If the cord is damaged a new cord must
be fitted by a Miele approved service
technician.
 WARNING - THIS APPLIANCE
MUST BE EARTHED

Miele H 2861 BP Specifications

General

Grill	Yes
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Cord length	1.5 m
Control type	Rotary
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Control panel material	Glass
Clock type	Electronic
Timer type	Digital
Timer modes	Cooking time
Current	16 A
Connected load	3600 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	0.71 kWh
Energy consumption (forced convection)	1.1 kWh
Lamp type	Halogen
Lamps quantity	1 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	595 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	590 mm
