Cleaning and care
69
If the locking clamps are not locked,
the door could become loose,
resulting in damage.
Always ensure that the locking
clamps are locked after refitting the
door.
 To relock the locking clamps, turn
them back up to the horizontal
position as far as they will go.
Removing the side runners
with FlexiClip runners
The side runners can be removed
together with the FlexiClip runners (if
inserted).
If you wish to remove the FlexiClip
runners separately beforehand, please
follow the instructions in “Features” –
“Fitting and removing FlexiClip runners”.
 Danger of injury caused by hot
surfaces.
The oven gets hot during operation.
You could burn yourself on the
heating elements, oven compartment
or accessories.
Allow the heating elements, oven
compartment and accessories to
cool before removing the side
runners.
 Pull the side runners out of holder(1.)
and remove them(2.).
Reassemble by following these
instructions in reverse order.
 Insert the components carefully.

Miele H 2861 BP Specifications

General

Grill	Yes
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Cord length	1.5 m
Control type	Rotary
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Control panel material	Glass
Clock type	Electronic
Timer type	Digital
Timer modes	Cooking time
Current	16 A
Connected load	3600 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	0.71 kWh
Energy consumption (forced convection)	1.1 kWh
Lamp type	Halogen
Lamps quantity	1 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	595 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	590 mm
