Miele PDR 908 HP User Manual

Operating the tumble dryer
23
Tip: For some settings, depending on
the value range and increments, the
value can also be set using a numerical
keypad. Briefly touching a number will
bring up the numerical keypad. Once a
valid number has been entered, the
OKsensor will be highlighted green.
OK
12 00
11 59
10 58
13 01
14 02
Clock display

 Briefly touch a number between the
two lines.
The numerical keypad will appear.
OK
12:00
3
4
21
Clock display
5 6
7

8
0
9
 Touch the numbers and confirm with
OK.
Pull-down menu
The pull-down menu can be used to dis-
play information, e.g. about a drying pro-
gramme.
 11:02

Cottons
Status
Time left
h2:27
Drying


If an orange bar appears at the top of
the screen in the middle of the display,
you can open the pull-down menu.
Touch the bar and drag down with your
finger.
Exiting a menu
 Touch the sensor to return to the
previous screen.
Entries made before this which have not
been confirmed withOK will not be
saved.
Help display
With some menus, Help appears along
the bottom line of the display.
 Touch the Helpsensor to display the
text.
 Touch the Closesensor to return to
the previous screen.

Miele PDR 908 HP Specifications

General

Door hinge	Left
Drum volume	130 L
Control type	Touch
Loading type	Front-load
Product color	Stainless steel
Built-in display	Yes
Custom panel-ready	No
Appliance placement	Freestanding
Drying system	Heat pump
Drying capacity	8 kg
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	-
Maximum spin speed	- RPM
Noise level (drying)	- dB
Door opening angle	167 °
Current	10 A
Connected load	1440 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	777 mm
Width	605 mm
Height	850 mm
Weight	72000 g
Package depth	820 mm
Package width	660 mm
Package height	940 mm
Package weight	78000 g
Door opening diameter	370 mm
