Miele PDR 908 HP User Manual

Initial commissioning
27
Reference to external appli-
ances
A reference to external hardware ap-
pears.
 Confirm with the OKsensor control.
Connect the XCI box or XCI-AD ac-
cessory unit before using the appli-
ance for the first time. Alternatively,
slide a communication module into the
slot on the back of the tumble dryer.
The tumble dryer must be disconnec-
ted from the mains for this process.
Then start the commissioning process.
Setting the display brightness
You will be asked to select the bright-
ness of the display.
OK
Display brightness
Darker Brighter
 Touch the segment bars until you
reach the required level of brightness.
The selected brightness level will be
highlighted orange.
 Confirm with OK.
The display will change to the next set-
ting.
Setting the date
OK
Date
21
22
24
25
2026
2025
202423 July
August
September
June
May
2023
2022
 Place your finger on the value that you
want to change and move your finger
in the direction you want.
 Once all values have been selected,
confirm with the OKsensor.
The display will change to the next set-
ting.

Miele PDR 908 HP Specifications

General

Door hinge	Left
Drum volume	130 L
Control type	Touch
Loading type	Front-load
Product color	Stainless steel
Built-in display	Yes
Custom panel-ready	No
Appliance placement	Freestanding
Drying system	Heat pump
Drying capacity	8 kg
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	-
Maximum spin speed	- RPM
Noise level (drying)	- dB
Door opening angle	167 °
Current	10 A
Connected load	1440 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	777 mm
Width	605 mm
Height	850 mm
Weight	72000 g
Package depth	820 mm
Package width	660 mm
Package height	940 mm
Package weight	78000 g
Door opening diameter	370 mm
