Installation
*INSTALLATION*
86
Drainage accessories, included
a. Hose extension
b. Adapter
c. Hose clip
d. Non-return valve
e. Hose holder
Example: Connected directly to a sink
drain outlet
1. Adapter
2. Nut
3. Hose clip
4. Hose extension
5. Non-return valve and hose clips
6. Tumble dryer drain hose
 Install adapter 1 to the sink drain out-
let using nut 2.
The nut is usually fitted with a washer
which must be removed.
 Attach the end of the hose 4 to ad-
apter 1.
 Use a screwdriver to tighten hose clip
3 up close to the nut.
 Insert the non-return valve 5 into the
tumble dryer's drain hose 6.
Install the non-return valve 5 so that
the arrow points in the direction of
flow (towards the sink).
 Secure the non-return valve using
hose clips.

Miele PDR 908 HP Specifications

General

Door hinge	Left
Drum volume	130 L
Control type	Touch
Loading type	Front-load
Product color	Stainless steel
Built-in display	Yes
Custom panel-ready	No
Appliance placement	Freestanding
Drying system	Heat pump
Drying capacity	8 kg
Delay start (max)	24 h
Residual moisture	48 %
Spin-drying class	-
Maximum spin speed	- RPM
Noise level (drying)	- dB
Door opening angle	167 °
Current	10 A
Connected load	1440 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	777 mm
Width	605 mm
Height	850 mm
Weight	72000 g
Package depth	820 mm
Package width	660 mm
Package height	940 mm
Package weight	78000 g
Door opening diameter	370 mm
