mRoy Series Capacity/Pressure Selection - Metallic Liquid Ends
●Capacies shown are for simplex. Double capacity for duplex
●Actuators, rupture detecon, and high viscosity opons require capacity derang per the table on the next page
●Plasc liquid ends are limied to 150 psi - 10 bar
mRoy
Series
Plunger
Gear
Rao
Code
Strokes/Minute
Capacity / Pressure @ 60 hz 1725 RPM Capacity / Pressure @ 50 hz 1425 RPM
60 hz
1725
RPM
50 hz
1425
RPM
Rangs at
100 psi/7 bar
Capacity at Max pressure
Rangs at
100 psi/7 bar
Capacity at Max pressure
Diameter Code
Capacity Max Pressure Capacity Max Pressure
GPH L/hr GPH L/hr PSI Bar GPH L/hr GPH L/hr PSI Bar
A
3/8”
9.5 mm
C
77 23 19 0.36
1.4
0.20
0.8
2000 137.9
0.30 1.1 0.17 0.6 2000 137.9
48 37 30 0.73
2.8
0.34
1.3
2000 137.9
0.61 2.3 0.28 1.1 2000 137.9
24 73 60 1.44
5.5
0.68
2.6
2000 137.9
1.20 4.5 0.57 2.2 2000 137.9
15 117 96 2.32
8.8
1.09
4.1
2000 137.9
1.93 7.3 0.91 3.4 2000 137.9
10 185 152 3.64
13.8
1.72
6.5
2000 137.9
3.03 11.5 1.43 5.4 2000 137.9
8 - 178
- - - -
- -
3.55 13.4 1.67 6.3 2000 137.9
7/16”
11.1 mm
D
77 23 19 0.57
2.2
0.4
1.5
1800 124.1
0.48 1.8 0.33 1.2 1800 124.1
48 37 30 0.8
3
0.6
2.3
1800 124.1
0.67 2.5 0.50 1.9 1800 124.1
24 73 60 1.7
6.4
1.2
4.5
1800 124.1
1.42 5.4 1.00 3.80 1800 124.1
15 117 96 2.8
10.6
2
7.6
1800 124.1
2.33 8.8 1.67 6.30 1800 124.1
10 185 152 4.4
16.7
3.1
11.7
1800 124.1
3.67 13.9 2.58 9.80 1800 124.1
8 - 178
- - - -
- -
4.30 16.3 3.02 11.40 1800 124.1
5/8”
15.9 mm
E
48 37 30 1.8
6.8
1.6
6.1
700 48.3
1.50 5.7 1.3 5.0 700 48.3
24 73 60 3.8
14.4
3.5
13.2
925 63.8
3.17 12 2.9 11.1 925 63.8
15 117 96 6.2
23.5
5.7
21.6
925 63.8
5.17 19.6 4.8 18.0 925 63.8
10 185 152
9.4 35.6 8.4 31.8
925 63.8
7.83 29.6 7.0 26.5 925 63.8
8 - 178
- - - -
- -
9.17 34.7 8.2 31.0 925 63.8
1 1/16”
27 mm
F
48 37 30 6.1
23.1
5.5
20.8
350 24.1
5.08 19.2 4.6 17.3
350 24.1
24 73 60 12.3
46.6
11.2
42.4
350 24.1
10.25 38.8 9.3 35.3
350 24.1
15 117 96 19.4
73.4
18.1
68.5
350 24.1
16.17 61.2 15.1 57.1
350 24.1
10 185 152 30.0
113.6
29.0
109.8
200 13.8
25.00 94.6 24.2 91.5
200 13.8
8 - 178
- - - -
- -
29.28 110.8 28.3 107.1
200 13.8
RPM1029 KIT MRB-L/R PVDF VITON ORING PLGR CODE L,R
RPM1030 KIT MRB-L/R PVDF EPDM ORING PLGR CODE L,R
RPM1031 KIT MRB-L/R PVDF TEFLEX ORING PLGR CODE L,R
Figure 5. RPM KITS
Figure 6. mRoy A Metallic Liquid End Capacity Tables
