46Installation, Operations & Maintenance Manual
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
10
Housing, Main Consult with aftermarket group for re-
placement. Provide serial number and
model number of pump.
1
20 Cup, Race 409-0064-020 Steel 1
30 Poppet, Relief Valve 212-0056-074 Nylon 1
40 Spring, Relief Valve 280-0043-041 Steel 1
50 Adjusting Screw, Relief Valve 405-0241-014 Steel 1
60 Plug - 1/4” NPT, Sq. Head 402-0009-111 Steel 1
70
Gear Shaft Bushing, (factory in-
stalled, not recommended for eld
service, call factory)
237-0029-006
Steel
1
80
Housing Sleeve 7/16”, High viscosity
option only
237-0073-006
Steel
1
90
Plunger, 7/16” 212-0055-006 Steel 1
Plunger, 3/8 212-0055-106 Steel 1
Plunger, 5/8” 212-0054-006 Steel 1
Plunger, 1-1/16” 212-0053-006 Steel 1
100 Rod, Connecting 214-0025-062 Aluminum 1
110 Pin, Wrist 211-0030-006 Steel 1
125
Gear Spacer, Simplex 219-0071-006 Steel 1
Gear Spacer, Duplex 219-0109-006 Steel 1
130
Gear Shaft, Simplex 268-0021-006 Steel 1
Gear Shaft, Duplex 268-0018-006 Steel 1
140
Plug, 1” NPT Socket Hex Head 402-0095-061
1
Plug, 1/2” NPT Socket Hex Head 402-0095-041
1
150 O-Ring, Parker 2-011 408-0109-082 Polyurethane 3
160 Control Spool 268-0037-006 Steel 1
170 Sleeve, Threaded 243-0058-016 316SS 1
180
Screw, Socket Set - 6-32NC x 1/4 405-0039-035
1
190
Plate, % Capacity 253-0015-062 Aluminum
1
200 Ring, Calibration 253-0024-062 Aluminum 1
Ring, Calibration 253-0024-071 PVC
1
210 Knob, Control 255-0019-016 316SS 1
Knob, Capacity Adjust 255-0019-071 PVC
1
6.3 BASIC PARTS LIST FOR DRIVE MODELS mRoy A (FIGURES 17 &18)
- Parts Not Illustrated
Parts Continued Next Page
